| 是否有現貨： | 否 | 品牌： | 其他 |
| 加工定制： | 是 | 轉速： | 3600 |
| 電機功率： | 00 | 類型： | 直流風扇 |
| 電壓： | 12V,24V,48V | 電流： | 0.23 |
| 適用范圍： | 12-48 | 風量： | 60CFM |
| 風葉直徑： | 60MM | 型號： | 6015 |
| 規格： | 60*60*15 | 包裝： | 300 |
| 產量： | 100000 |
不支持線上交易，圖片和價格僅供參考，有需要歡迎來電咨詢進一步探討具體產品和參數細節，謝謝！
電話：0755-86039455 0769-82753256
傳真：0769-82753856
企業QQ:2850360250,2860360251，2850360255
深圳市禹臣慧博科技有限公司是從事電散熱系列產品的研發、銷售、生產的風扇制造企業。
DC風扇型號齊全，外形尺寸有：25*25*06、30*30*10、35*35*15、40*40*（10/20/28、）50*50*（10/15）、60*60*（10/15/20/25/38）、70*70*(15/25)、80*80*（15/20/25）、92*92*（25/38）、120*120*（25/38）等，電壓可提供5V、12V、24V、48V等。
我們將不懈努力，力求為您提供符合成本效益的產品和服務。和與您一起創造美好的未來。
Item
Specification
Test Condition
1
Rated Voltage
V ±10%
DC power supply
2
Rated Current
Amp (Typical)
DC power supply at Rated Voltage
3
Amp(SafetyRegulation)
DC power supply at Rated Voltage.
This is for Safety Regulation.
4
Rated Power
2.16W
AtRated Voltage.
5
Starting Voltage
7V (Max.)
DC power supply
6
Insulation Resistance
10 MΩ (Min.)
Input 500V(DC) between
Lead wire(+) and housing
7
Speed
RPM ±10%
Measured at 5 minutes
after starting under 25±5℃, 65±5%RH ambient
8
Acoustical Noise
dB(A)(measurement tolerance ± 2 dBA)
Measured at typical speed with an acoustic microphone 1 meter away from the fan intake in a test chamber with background noise level below 18dB(A)under ISO-3745 Standard, refer to NOISE MEASUREMENT ITEM 7.
9
Static Pressure
mm-H2O
(inch-H2O )
Refer to PERFORMANCE CHART ITEM 9 at zero airflow.
This measurement is performed AMCA 210-99 Standard.
10
Air Flow
CFM
(CMM )
Refer to PERFORMANCE CHART ITEM 9 at zero static Pressure.
This measurement is performed AMCA 210-99 standard.
11
Direction of rotation
Counter-anticlockwise
DC power supply, viewed from impeller.
